Press release: Perfect SMD stencils with personalised customer service

Weitefeld, October 2024 - Small process, big impact: solder paste printing is a neuralgic point in electronics production.
point in electronics production, and the SMD stencil is the decisive tool for it. The
BECKTRONIC GmbH, the specialist for high-precision laser-cut SMD stencils, not only offers
outstanding products, but also attaches great importance to comprehensive customer advice.
Customers benefit from the company's many years of expertise, particularly in the area of fixed-framed stencils.
expertise of the company. Consultancy support in the selection of the right stencil
ensures customised solutions for individual requirements.

Consultancy service as the key to optimum stencil selection

Numerous technical factors play a decisive role in the selection of the right SMD stencil.
decisive role. The material, stencil thickness, aperture design and surface treatment
significantly influence the precise application of the solder paste and therefore the quality of the end product.
The choice between fixed-framed stencils and quick-release systems also has an impact
on stability and handling, especially with high production volumes. Other important
other important criteria are machine compatibility, the durability of the stencil and economic efficiency
in terms of production costs and the number of possible doctor blade cycles.

The complexity of these factors requires sound advice in order to ensure that the
stencil is optimally matched to the individual requirements of the respective production process.
requirements of the respective production process. The wrong choice can lead to production errors, increased waste and unnecessary costs.
costs. BECKTRONIC therefore offers proactive customer advice in which all relevant parameters are
parameters into the decision-making process. Thanks to the company's expertise, the
stencil selection becomes a customised process that ensures efficiency and precision in electronics production.
electronics production.

Focus on fixed-framed SMD stencils

BECKTRONIC pays particular attention to the area of fixed-framed stencils, which still have numerous applications in modern electronics production.
still have numerous areas of application in modern electronics production. Fixed-framed
stencils are characterised by their high stability, which prevents deformation during the printing
prevents deformation during the printing process and thus ensures precise paste application. Handling is
handling is significantly easier and faster due to the fixed frame, which reduces set-up times and
efficiency. In addition, fixed-framed stencils are particularly durable, as they are less stressed by the
frame and can cope with a higher number of doctor blade cycles.

Precisely matching these factors to the customer's requirements ensures
that the stencil provides maximum benefit and increases process efficiency. Particularly
worth mentioning here is the advice regarding the choice between the different types of
types of fixed-framed stencils, such as the classic fabric-covered frame design or
directly bonded variants.

Exclusive from BECKTRONIC: Directly bonded stencils

BECKTRONIC is the only manufacturer to offer directly bonded SMD stencils. This exclusive
This exclusive product solution enables a particularly stable connection between stencil and frame, which
simplifies handling considerably and increases precision during pasting. The direct
The direct bonding prevents the risk of vibrations or unintentional movements, which leads to an
exact application of the solder paste. This type of stencil is particularly suitable for high-precision and
sensitive applications where the smallest inaccuracies can have serious consequences for the electrical
electrical conductivity and functionality of the end product.

Customised solutions thanks to individual advice

In addition to the high product quality, it is above all the customer-orientated advice that sets BECKTRONIC
stands out from other providers. Proactive customer advice not only includes the selection of
templates, but also the optimisation of the CAD data of the customer's layout. The customer data is often
customer data are often standardised layouts that do not take certain subtleties in the process
such as the shape and position of the apertures. Individual optimisation ensures that the
optimisation ensures that the design of the template is optimally adapted to the specific production process.
process. This leads to shorter throughput times and, above all, significantly fewer errors in the print image.
print image. Thanks to short service channels, fast response times and the comprehensive expertise of
expertise, BECKTRONIC can deliver customised solutions in the shortest possible time
- often within just one day. This enables customers to react flexibly to
customers to react flexibly to production requirements and to rely on a dependable partner.

Conclusion

BECKTRONIC GmbH not only offers first-class SMD stencils, but also highly professional
highly professional advice that is tailored to the individual needs of each customer.
Particularly in the area of fixed-framed stencils, customers benefit from the company's expertise and comprehensive
the company's expertise and comprehensive consulting service. The exclusive option of receiving directly
stencils as well as the fast and flexible responsiveness make BECKTRONIC an indispensable partner in the
an indispensable partner in electronics production.
